• 12-inch 2-way surface-mount installation loudspeaker
  • 300 W rated power, 8-ohm low-impedance
  • 75-degree conical coverage pattern
  • Max continuous SPL 120 dB (126 dB peak)
  • IP-54 weather resistance for indoor/covered outdoor use
  • X-Mount yoke and Euroblock input included
  • Black painted ABS enclosure with aluminum grille
Price: $1,235.00
    Availability: In Stock
    Usually ships In 24 - 48 hours

    Item #: AD-S12-BK

    Description

    The QSC AD-S12 is a 12-inch, two-way surface-mount loudspeaker from the AcousticDesign Series, built for foreground and background sound reinforcement in commercial spaces such as restaurants, retail floors, houses of worship, schools, and transit terminals. It pairs a weather-resistant 12-inch woofer with a 1-inch-exit compression driver in a rugged, low-impedance (8 ohm) enclosure that resists dust and splashing, making it suitable for both interior and covered exterior installs. This is the black finish.

    Key Features

    • 12-inch LF woofer plus 1.4-inch compression driver in a 2-way design
    • 8-ohm, 300 W rated low-impedance operation
    • Even 75-degree axisymmetric coverage for consistent tonal balance
    • IP-54 rated weather-resistant construction for indoor or covered outdoor use
    • Includes X-Mount bracket, Euroblock connector, and input panel cover

    Specifications

    Type12" 2-way surface-mount loudspeaker
    LF driver12" woofer, 2.5" voice coil
    HF driver1" exit, 1.4" compression driver
    Rated power300 W
    Impedance8 ohms
    Frequency range52 Hz - 20 kHz
    Sensitivity95 dB (1W/1m)
    Max SPL120 dB cont. / 126 dB peak
    Coverage75 degrees axisymmetric
    ConnectorEuroblock with parallel output
    IP ratingIP-54
    Dimensions23.4 x 13.9 x 12.7 in
    Weight35.2 lb
