- Up to 64x64 AVB Streams of digital audio networking with Biamp AVB devices
- Up to 128 x 128 channels of digital audio networking with Biamp AVB devices
- 32 x 32 channels of digital audio networking via the Dante protocol
- AES67-enabled Dante endpoint
- 2 mic/line level inputs, 2 mic/line level outputs
- Five 1 Gigabit Ethernet Ports
- Four ports support PoE+ power (IEEE 802.3.at Class 4, 30W)
- Up to 2x2 channels of configurable USB audio
- 16 AEC channels assignable to any input
- 4-pin GPIO
- Surface mountable with included bracket
- Supports port authentication via IEEE 802.1X
- SIP VoIP interface via Gigabit Ethernet connection
- CE marked, UL listed, and RoHS compliant
- Covered by Biamp Systems’ 5-year warranty
Availability: In Stock
Usually ships In 24 - 48 hours
notify me
Item #: TesiraFORTÉ X 1600
Description
TesiraFORTÉ X 1600 is a meeting room DSP featuring multiple network and analog audio connection points, with 16 channels of Acoustic Echo Cancellation (AEC) assignable across any digital or analog input. Five 1-Gigabit Ethernet ports are provided, four of which are PoE+ powered, and which support media and control traffic of various types including AVB, Dante and VoIP.
Specifications
- Depth: 8.11 in
- Height: 1.47 in
- Number of Channels: up to 2
- Sample Rate: 48kHz
- Width: 8.11 in
- Altitude: 0-6,600 feet (0–2000 Meters) MSL
- Humidity: 0–98%, non-condensing
- Input Impedance (Balanced): 8kohm
- Maximum Input: +24dBu
- Output Impedance (Balanced): 207ohm
- Product Weight: 1.90 lbs
- Active Power: 30 Watt
- Ambient Operating Temperature Range: 32-104° F (0–40° C)
- AC Voltage (Minimum): 100 Volts
- AC Voltage (Maximum): 240 Volts
- EIN (no weighting, 22Hz to 22kHz): < -125dBu
- USB Bit Depth: 24-bit
- Frequency Response 20Hz to 20kHz, +4dBu output: +0.25 dB/-0.5 dB
