- ACH or Wire Transfer Payment required
- System includes
- Open Box Items - new never used or installed just opened boxes and repacked them.
- 1 - C3500 M# AH-DLIVE-DLC35
- 1 - CDM-132 M# AH-DLIVE-CDM32
- 4 - Digital Breakout Box 16X8 M#AH-DX168
Specs and features
- Measured balanced XLR in to XLR out, 20-20kHz, minimum Gain, Pad out
- Dynamic Range: 110dB
- System Signal to Noise: -92dB
- Frequency Response: 20Hz - 30kHz +0/-0.8dB
- THD+N (analogue in to out): 0.0015% @ +16dBu output, 1kHz 0dB gain
- Headroom: +18dB
- Internal operating Level: 0dBu
- dBFS Alignment: +18dBu = 0dBFS (+22dBu at XLR output)
- Meter Calibration: 0dB meter = -18dBFS (+4dBu at XLR out)
- Meter Peak indication: -3dBFS (+19dBu at XLR out)
- Sampling Rate: 96kHz +/- 20 PPM
- ADC: 24-bit Delta-Sigma
- DAC: 24-bit Delta-Sigma
- Latency:
0.7 ms (MixRack XLR in to XLR out, input to Mix)
+5 samples, Surface to MixRack (GigaACE hop)
+8 samples, DX32 to MixRack (DX hop) - Operating Temperature Range: 32°F to 95°F
- Mains Power: 100-240V AC, 50-60Hz, 110W max
- USB Audio Playback: Mono/stereo .WAV files, 16/24bit, 44.1/48/96kHz
- USB Audio Recording: Stereo .WAV files, 24bit 96kHz
Dimensions and Weights - C3500 - boxed (WxLxH): 34.3 x 41.7 x 18.9inch
- Weight: 82.7Lbs
We are an A&H Dealer. As such, this unit is brand new in the original manufacturers boxes. The c3500 box has been opened for inspection and a one day training for our staff. DX168s are sealed new, CDM-32 is open and new never powered up, set out for display during training.
