The QSC SR-1020 is a two-way cinema surround loudspeaker from QSC's SR-series (Digital Cinema Sound), designed for the side and rear surround arrays of a commercial theater. It uses a 10-inch low-frequency driver with a horn-loaded high-frequency section to give even, wide coverage along auditorium walls. Its axisymmetric 90 by 90 degree pattern makes it easy to space uniformly for smooth surround imaging.
Key Features
- Two-way cinema surround loudspeaker
- 10-inch low-frequency driver with horn-loaded high-frequency section
- Approximately 90 x 90 degree axisymmetric coverage
- Roughly 94 dB sensitivity for efficient surround-array operation
- Designed for side and rear surround positions in cinemas
