• 15-inch two-way passive/bi-amp install loudspeaker
  • 75-degree axisymmetric coverage
  • 625 W continuous, 8-ohm impedance
  • 123 dB continuous SPL (passive mode)
  • NL4 speakON and covered barrier strip inputs
  • 15x M10 inserts for suspension or yoke mount
Price: $1,921.00
    Availability: Pre-Order

    Item #: AP-5152-WH

    Description

    The QSC AP-5152-WH is the white-finish version of the AcousticPerformance AP-5152, a 15-inch two-way high-power installation loudspeaker. Designed for large fixed installs including cinemas, houses of worship, theaters and performance venues that need discreet white cabinets, it combines a 381 mm woofer with a 102 mm voice coil and a 76 mm compression driver on an axisymmetric waveguide for focused 75-degree coverage. Switchable bi-amp/passive operation and fifteen M10 rigging inserts add install flexibility.

    Key Features

    • 15-inch two-way high-power installation loudspeaker
    • 75-degree axisymmetric coverage
    • 625 W continuous power handling at 8 ohms
    • 123 dB continuous SPL in passive mode
    • White (RAL 9010) enclosure with switchable bi-amp/passive and 15 M10 fly points

    Specifications

    Type15-inch two-way, passive/bi-amp
    LF driver381 mm, 102 mm voice coil
    HF driver76 mm voice coil compression driver
    Power625 W continuous
    Coverage75 degrees axisymmetric
    Sensitivity96 dB, 1 W @ 1 m
    Max SPL123 dB continuous (passive)
    Impedance8 ohms
    Dimensions813 x 445 x 386 mm
    Weight36.2 kg (80 lb)
